臺灣JK積奇三相SCR電力調整器 電感性負載

 (適用於變壓器與非電阻性負載)

規格說明

1.主電源電壓: AC 220V 380-480V ±10%

2.輔助電壓: AC 220V±15% 50/60Hz

3.額定電流: 25A-750A

4.工作頻率: 47-63Hz

5.輸出方式: 相位控制輸出

6.相位輸入控制訊號: 4-20mA, 0-5V, 1-5V, 0-10V, 2-10V。

7.輸出電壓范圍: 0-100%

8.使用環境: -10度-50度 濕度 90%RH以下

9.絕緣阻抗: 20 MΩ 以上(電源與外殼間)、20 MΩ 以上(輸入信號與外殼間)

10.耐壓強度: 電源與外殼間 2500VAC/1分鐘、電源與輸入信號 1000VAC/1分鐘

四、型號規格：

三相三線相位控制：

JK3PTS-22025, JK3PTS-22035, JK3PTS-22050,JK3PTS-22060, JK3PTS-22080, JK3PTS-22100, JK3PTS-22125, JK3PTS-22160, JK3PTS-22180, JK3PTS-22200, JK3PTS-22225, JK3PTS-22250, JK3PTS-22300, JK3PTS-22350, JK3PTS-22400, JK3PTS-22600, JK3PTS-22750
JK3PTS-48025, JK3PTS-48035, JK3PTS-48050,JK3PTS-48060, JK3PTS-48080, JK3PTS-48100, JK3PTS-48125, JK3PTS-48160, JK3PTS-48180, JK3PTS-48200, JK3PTS-48225, JK3PTS-48250, JK3PTS-48300, JK3PTS-48350, JK3PTS-48400, JK3PTS-48600, JK3PTS-48750
