Compact-Size Box PC with Intel® Core™2 Duo Processor
產品亮點
- Compact size design with full I/O features
- 3.5” embedded SBC
Intel® Core 2 Duo Processor (Penryn)
Intel® GM45/ICH9-M chipset, 1x SO-DIMM DDR3 800/1066
- HDMI, DVI, USB 2.0, GbE
- SATA HDD, CF, COM, HD Audio
- Heavy-duty steel chassis with System Fan
特點詳情
The QDSP-2030 is a compact size Box PC ideal for space critical applications. This embedded hardware platform is based on a 3.5” industrial SBC with Intel® 45 nm Core™2 Duo Processor, Intel® GM45/ICH9-M chipset, and DDR3 800/1066 SO-DIMM. Featured are a 2.5” SATA hard drive bay, Internal Compact Flash Type II slot, HDMI, DVI, USB 2.0, COM, and HD Audio.
The QDSP-2030 provides high reliability for harsh environments, compact size, high performance and is highly suited to a wide range of industrial applications such as Digital Signage, Gaming, Transportation, Surveillance, and Thin Servers.
|
