產品亮點

• LGA775  Core 2 Duo/Pentium D/Celeron處理器
• Intel G41 + ICH7, FSB 800/1066MHz
• 2 x 240針DIMM DDR3 800/1066內存，高達4GB
• 2 x Realtek RTL8111E PCI-E千兆網口
• 4 x COM接口
• 8 x USB2.0
• 1 x PCI擴展插槽

特點詳情

>> 系統參數

CPU                             LGA775  Core 2 Duo/Pentium D/Celeron處理器

芯片組                           Intel G41 + ICH7, FSB 800/1066MHz
DRAM                            2 x 240針 DIMM DDR3 800/1066內存，高達4GB

BIOS                             8Mb AMI Flash ROM
電源                            1 x 20針 ATX電源接口, 支持AT/ATX模式
看門狗                          看門狗定時功能
規格                            170mm x 170mm

>> I/O端口

硬盤                                      2 x SATA-300接口

 串口                            4 x COM ports, (3*RS232, 1*RS232/422/485)
并口                                 1個并行打印口

音頻                                    Realtek ALC662 HD音頻解碼器, 支持5.1CH audio
鍵盤/鼠標                        2 x PS/2鍵盤鼠標

 網口                                       2 x Realtek RTL8111E PCI-E千兆網口

 USB                                       8 x USB2.0 (4個板載)

數字I/O                             4路進; 4路出
擴展槽                             1 x PCI擴展槽

>> 顯示

圖形                               Intel GMA X4500，最高可達512MB視頻內存

VGA                                      2048 x 1536最大分辨率

>> 環境

運行溫度                                  0°~60°C
相對濕度                                  10~90%

Model                               Description

SYS76841VGGA                Intel G41 Mini-ITX Board w VGA/2*Giga LAN/Audio
