產品亮點

• LGA775 支持Intel Core2 Quad/Core 2 Duo/Pentium D/Celeron D
• Intel G41 + ICH7/IC7R, FSB 800/1066MHz
• 2 x 240針 DIMM DDR3 800/1066內存，最高可達8GB
• 2 x Intel 82574L PCI-E千兆以太網接口
• 6 x COM ports，4 x SATAII，8 x USB2.0
• 1 x PCIeX16, 1 x PCIeX1, 5 x PCI插槽擴展

特點詳情

>> 系統參數

CPU                                   LGA775 支持Core 2 Quad Q9000系列/Core 2 Duo/Pentium D/Celeron D

芯片組                              Intel G41 + ICH7/ ICH7R(通過MOQ可選), FSB 800/1066/1333MHz

DRAM                                 2 x 240針 DIMM DDR3 800/1066，最高可達8GB

BIOS                                  8Mb AMI Flash ROM

電源                                    1 x 24針ATX電源接口, 支持AT/ATX 模式

看門狗                               看門狗定時器功能(重設: 1~65535級)

規格                                 305mm x 244mm

>> I/O端口

硬盤                                    4 x SATA-300接口, 支持RAID 0/1/5/10(ICH7R)

軟驅                                     1 x FDD 接口

串口                                   6 x RS232 COM端口

并口                               1個并行打印接口

音頻                                   Realtek ALC662 HD音頻解碼器, 支持5.1CH音頻

鍵盤/鼠標                          2 x PS/2 鍵盤鼠標

網口                                      2 x Intel 82574L PCI-E千兆以太網

USB                                      8 x USB2.0 (4個通過板載頭)

數字 I/O                            4路輸入; 4路輸出

擴展                                   1 x PCIeX16, 1 x PCIeX1, 5 x PCI插槽擴展

>> 顯示

圖形                              Intel GMA X4500, Max. 共享系統內存高達1759MB

VGA                                     2048 x 1536最大分辨率

DVI                                      2048 x 1536最大分辨率

>> 環境

運行溫度                              0°~60°C

相對濕度                              10~90%

訂購信息

Model                               Description

SYM76941VGGA                Intel G41 + ICH7 ATX mother-board w VGA/2*Giga LAN/Audio/6*COM

SYM76941VGGA-R             Intel G41 + ICH7R ATX mother-board w VGA/2*Giga LAN/Audio/6*COM/RAID
