*high-end PC board for the PCI bus
*microcontroller 68360 with real-time operating system
*up to 32 MB DRAM
*PCI-Bridge QSPAN CA91860
*additional interfaces: 1x RS-232 (optionally RS-422, RS-485, TTY), 3x serial (TTL level), 1x Ethernet (TTL level)
*CAN controller SJA1000, CAN 2.0A/B
*CAN interfaces electrically isolated and designed acc. to ISO 11898
*bit rate up to 1 Mbit/s
*software examples for DOS and Windows 3.11 in source code
*software drivers available for many operating systems
*CANopen master-slave object licence available
*also available for DeviceNet
